Print Head / Ink
Type - Fine Cartridge
Number of Nozzles - Total 1,280 nozzles
Ink Cartridges
PG-47, CL-57S (Optional: CL-57)
Maximum Printing Resolution
4800 (horizontal)*1 x 1200 (vertical) dpi
Print Speed
Document (ESAT/Simplex) - Approx. 8.8 ipm (black) / 4.4 ipm (colour)
Printable Width - Up to 203.2 mm (8 inch)
Bordered Printing - Top margin: 3 mm, Bottom margin: 16.7 mm, Left/Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)
Recommended Printing Area
Top Margin - 31.6 mm
Bottom Margin - 29.2 mm
Paper Size - A4, A5, B5, Letter, Legal, 4x6", 5x7", Envelopes (DL, COM10), Custom size (width 101.6 - 215.9 mm, length 152.4 - 676 mm)
Paper Handling Rear Tray (Maximum Number) - Plain Paper
A4, A5, B5, Letter = 60 - Legal = 10
Photo Paper Plus Glossy II (PP-201) - 4x6" = 20, 5x7" = 10
Glossy Photo Paper (GP-508) - 4x6" = 20
Envelope - European DL / US Com. #10=5
Paper Weight - Rear Tray
Plain Paper: 64-105 g/m²,
Canon specialty paper: max paper weight: approx. 275 g/m² (Photo Paper Plus Glossy II, PP-201)
Ink End Sensor
Dot count
Print Head Alignment
Manual
Scanner Type
Flatbed
Scanner Method
CIS (Contact Image Sensor)
Optical Resolution
Optical resolution scan is available, only when you use TWAIN Driver.
600 x 1200 dpi
Selectable Resolution
25 - 19200 dpi
Scanning Bit Depth (Input/Output)
Grayscale - 16 bit/8 bit
Colour - 48 bit / 24 bit (RGB each 16 bit / 8 bit)
Line Scanning Speed
Grayscale - 1.2 ms/line (300 dpi)
Colour - 3.5 ms/line (300 dpi)
Scanning Speed
Reflective (A4 Colour / 300dpi) - Approx. 19 sec
SCAN / COPY Maximum Document Size - Flatbed A4/LTR (216 x 297 mm)
Compatible Media
Size - A4, Letter
Type - Plain Paper
Image Quality - Plain Paper: Draft, Standard
Copy Speed
Document (sFCOT/Simplex) - Approx. 30 sec
Document (sESAT/Simplex) - Approx. 1.8 ipm
Multiple Copy
Black/Colour - 1 - 21 pages
System Requirements*9
Windows 10 / 8 / 7 SP1, Windows Vista SP2
Mac OS X 10.8.5 and later
Interface
Hi-Speed USB 2.0
Operating Environment
Temperature - 5 - 35°C
Humidity - 10 - 90% RH (no dew condensation)
Recommended Environment
Temperature - 15 - 30°C
Humidity - 10 - 80% RH (no dew condensation)=
Storage Environment
Temperature - 0 - 40°C
Humidity - 5 - 95% RH (no dew condensation)
Quiet Mode - Available
Acoustic Noise*12 (PC Print) - 46.0 dB(A)
Power - AC 100-240 V, 50/60 Hz
Power Consumption - OFF Approx. 0.4 W
Standby (Scanning lamp is off) - Approx.1.0 W
Copying - Approx. 9 W
Printing - Approx. 9 W
Dimension (WxDxH)
Approx. 426 x 306 x 145 mm
Weight
Approx. 3.4 kg
Page Yield
Standard: PG-47: 400 / CL-57S: 180 / Optional: CL-57: 300
